RailEasy Flatbase Swivel
Request Quote
RailEasy Flatbase Swivel
Request a Quote
The RailEasy™ Swivel End is designed for cable railing applications and is used with a RailEasy™ Tensioner to apply cable tension. The slotted base allows for installation at angles up to 45 degrees, and its round shape is made to fit 2 in outside diameter stainless tubing. Rivets are required for attachment and are included with complete SunRail™ systems.
- Product #: S0981-S004
- Finish: Type 316 Stainless Steel
- Size: 5/32 in
- Weight: 0.12 lbs/ea
- Slotted base allows 45 degree cable angle
- Used in conjunction with Tensioner S0981-0004
Product Specifications
Code:
S0981-S004
Railing Type
Swivel End
Additional Product Info
Additional Specifications
RailEasyTM Swivel End (non-tensioning, requires a RailEasyTM Tensioner at the opposite end)The RailEasy™ Swivel End is designed for use in short runs and straight sections less than 25 feet. It must always be used with a RailEasy™ Tensioner at the opposite end of the cable run for tensioning capabilities. The compression fitting holds the cable using simple hand tools and the slotted base allows for angles up to 45 degrees, making it ideal for stair applications. The swivel ends are surface mounted with three #8 1-1/2 in stainless steel screws.
Other Specifications
| A: | 5/32 in |
| B: | 5.40 in |
| C: | 2.26 in |
| D: | 0.31 in |
| FAST: | #8 |
| QTY: | 1 |
